Detailed Product Information
Product Description
The test bench is used for commissioning, repairing and testing Cummins PT pump and PT electronic fuel pump. Its features are as follows:
Main Features
- Adopting human-machine intelligent interface, full digital display of various parameters, powerful database and dynamic display, making it more convenient for users
- Imported high-precision flow, pressure, temperature sensors and transmitters can make the measurement accuracy higher.
- Adopting imported frequency conversion speed controller, high reliability and energy-saving.
- According to the user’s needs, it can be connected to the desktop computer, which is convenient for archiving, printing and network management.
Specification
| Speed | 0-4200 R.P.M |
| Main Flowmeter | 75-2400Lb/h |
| Vacuum Gauge | 0-30 in. Hg |
| Power Consumption | 5.5kw |
| Direct Power Supply | 0-30V 3A |
| Dimensions(mm) | 600×1000×1630 |
| Pressure Gauge | 0-400psi |
| Idle/Leakage Flowmeter | 10-760 cc/min |
| Air Pressure Gauge | 0-30psi |
| Power Supply | AC 38OV 50Hz |
| Fuel Temperature | 38±2℃ |
| Weight | 350kg |
