LS280GF Cummins NTA855-G1 280KW Diesel Engine Rainproof Generator

LS280GF Cummins NTA855-G1 280KW Diesel Engine Rainproof Generator



Detailed Product Information

Product Description

Briefly describe what the form is for or provide additional context if required. Use inviting language. Briefly describe what the form is for or provide additional context if required. Use inviting language. Briefly describe what the form is for or provide additional context if required. Use inviting language. Briefly describe what the form is for or provide additional context if required. Use inviting language. Briefly describe what the form is for or provide additional context if required. Use inviting language. Briefly describe what the form is for or provide additional context if required. Use inviting language.

Main Features

  • PT Fuel System – uses the time-tested and proven PT fuel system for high performance and ease of maintenance.  PT injectors are built to handle high pressures for optimum combustion.
  • Fillet-Hardened Crankshaft – smaller bolt circle and rolled threads for strength and durability
  • Cummins Prelub System – Distributes and pressurizes oil in the engine before cranking can occur, and is proven to greatly extend life-to-rebuild.
  • Galley-cooled pistons – reduced piston crown temperatures by as much as 100°F (38°C) for enhanced durability, reduced piston ring wear and 30% longer cylinder life.
  • Turbochargers – Custom-built for K Series engines and are available in single-stage or two-stage configurations to meet any application’s requirement.

Generator Specification

Generator ModelLS280GF
Engine ModelNTA855-G1
Rated speed1500rpm
Fuel Consumption(L/h)61
Prime Power250KW/313KVA
Standby Power280KW/350KVA
Length(mm)3300
Width(mm)1300
Height(mm)1750
Net Weight(kg)3150

Rainproof Generator Set List

Generator ModelEngine ModelStandby PowerPrime PowerSpeed   Fuel Consumption
kWkVAkWkVArpmL/h
LS22GF4B3.9-G2222820251500 5
LS26GF4B3.9-G2263324301800 6
LS36GF4BT3.9-G2364532401500 8
LS40GF4BT3.9-G2405036451800 9
LS50GF4BTA3.9-G2506345561500 13
LS60GF4BTA3.9-G2607554681800 14
LS75GF6BT5.9-G2759468851500 17
LS85GF6BT5.9-G28510675941500 19
LS90GF6BT5.9-G290113801001800 20
LS100GF6BTA5.9-G2100125901131500 23
LS110GF6BTA5.9-G21101371001251500 25
LS120GF6BTAA5.9-G21201501101371500 26
LS132GF6BTAA5.9-G21321651201501800 30
LS140GF6CTA8.3-G21401751201501500 30
LS160GF6CTA8.3-G21602001401751800 36
LS180GF6CTAA8.3-G21802251602001500 40
LS220GFNT855-GA2202752002501800 41
LS250GFNTA855-G1A2503132202751500 55
LS280GFNTA855-G12803502503131800 61
LS300GFNTA855-G1B3003752753441800 68
LS315GFNTA855-G43153942803501500 68
LS330GFNTAA855-G73304133003751500 73
LS350GFNTA855-G33504383204001800 80
LS400GFKTA19-G24005003604501800 85
LS450GFQSZ13-G34505634005001500 98
LS450GFKTA19-G3A4505634005001500 98
LS500GFKTA19-G3A5006254505631800 113
LS505GFKTAA19-G55056314505631500 110
LS550GFKTAA19-G55506884705881800 117
LS560GFKTA38-G5607005006251500 122
LS570GFQSKTAA19-G35707135206501500 130
LS660GFKTA38-G26608386007501500 147
